FedEx Extract Fan

Competitors Required:

1

Description:

This event will test each participant's skill and speed while accomplishing the removal and installation of an Airbus A300 extract fan.

References:

• Task card to be provided

Tools, Equipment, and Materials Provided:

See task card

Snap-on provided tooling (qty one in each of two pallets unless otherwise indicated):

• Safety wire pliers (WTG8A)
• Cannon plug pliers (ATI508KG)
• Flat head screwdriver (SGD2BO)
• 0.020 safety wire (WT105-2016)
• 0.032 safety wire (WT105-3216)
• Diagonal cutters (808CF)
• 7/16 socket ( STMD14)
• 1/4 Ratchet ( THL72)
• 6-inch extension (TMXK60)
• O/Ring Extrator ( SGSR2AR)
• 1/4 Drive Torque Wrench (QD1R50A)
• Telescoping Inspection Mirror (UIM225)

Procedures:

Competitor will gain access to the A300 extract fan and follow the removal/replacement task card as written. Competitor will make all safety callouts, torque settings, and condition findings. Once the task card is completed, competitor must tell the judge, “Stop Time.”
