Eaton Rigid Tube Assembly Repair

Competitors Required:

2

Description:

Competitors will repair a rigid tube assembly using the Rynglok Axial Swage Tube Fitting System.

References:

• Eaton bulletin TF100-138 Rynglok Tube Fitting System assembly procedure and inspection guide
• Eaton bulletin TF100-1F Rynglok Fitting System Design Features and product overview
• Eaton bulletin TF100-75 Rynglok Fitting System AS-Standards Cross Reference

• (NAVY) NAVAIR 01-1A-20

  (AIR FORCE) T.O. 42E1-1-1

Tools, Equipment, and Materials Provided:

See Eaton Bulletin TF100-138.

Snap-on provided tooling (qty one in each of two pallets unless otherwise indicated): None

Procedures:

See Eaton Bulletin TF100-138

Penalties will be assessed for:

• Step 1 – Not selecting the correct RTSGO-01-08 Tool from the tool kit.
• Step 1 – Not marking tube correctly using RTSGO-01-08 Tool and marking pen.
• Step 2 – Not inserting the fitting to the correct depth on the tube per the position mark.
• Step 3 – Not selecting the correct size tool from the tool kit.
• Step 5 – Not swaging the fitting correctly and not passing the visual inspection using gauge RTSGO-51-08.
